Compact Triple-Stage Fridge Filter
Upgrade your fridge’s water and ice supply with the Triple-Stage Fridge Filter, engineered for homes where water purity and appliance protection matter most. This system blends three sequential filtration stages:
The Triple-Stage Fridge Filter System is installed behind the fridge and is easy to maintain.
The Triple-Stage Fridge Filter System will remove sediment, mud, dirt, rust, and chlorine, and inhibit the growth of bacteria.
The system has a bracket so it can be wall-mounted.
Benefits:
- Filtered water tastes and smells great
- Preserves the natural minerals in the water
- Removes chemicals such as Chlorine
- No water wasted during filtration
- Low maintenance
- Low filter replacement cost
- No electricity required
Triple Fridge Filter Kit Stages:
Stage 1: Inline Sediment Pre-Filter
Installed first in the water feed line, this filter removes visible particles such as sand, rust, and large debris — protecting subsequent filtration stages and your refrigerator’s internal water circuit.
Stage 2: Generic External Fridge Water/Ice Cartridge (Activated Carbon)
The second stage targets chlorine taste and odours, fine sediments and organic contaminants, restoring fresh flavour and clarity to your fridge water and ice output.
Stage 3: Hollow-Fibre Ultrafiltration (UF) Membrane
The final polishing stage uses a hollow-fibre UF membrane rated down to ≈ 0.2 µm with a typical flow of about 540 L/h, removing ultra-fine particles, bacteria, and suspended matter without altering mineral content.
Also, please note the UF Membrane does require flushing before use. Attach the filter system to the source water and let the water run through into a bucket until there is no more residue flowing. If there is still some residue after connecting to your fridge, please repeat the process.
By combining all three stages, you gain a comprehensive fridge-filtration chain: robust pre-filtration, taste & odour refinement, plus high-precision UF barrier blocking bacteria and other microparticles. The result is great-tasting water and ice, extended cartridge life, and enhanced protection for your refrigerator’s water system.
Installation is straightforward using standard ¼″ tubing. Replace the sediment pre-filter as required (depending on water quality), replace the taste/odour cartridge every six months (or sooner if needed), and the UF membrane annually for optimum performance.
Note: Do not use with a water source that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system.
Known Compatible Fridges and Filter:
LG 55616, 155083, 497818, 4210359, 4210508, 4210573, 4378411, 4392945, 18001001, 18001009, 18001010, 25004006, 25004018, 25004022, 25004082, 3010541600, 3019974100, 5303310266, 5303917335, 3650JD8050A, 3890JC2990A, 5231JA2003B, 5231JA2010A, 5231JA2010B, 5231JA2012A, AP2615841, AP3109540, AP3219862, AP4324927, BL9808, BL-9808, C00114417, CL10RO, DA29-10105C, DA29-10105E, DA29-10105J, DD7098, DD-7098, EF9603, EF-9603, GXITQ, GXRTO, GXRTQ, HAFEX-EXP, IF30, IF-30, IF30A, IF30-A, IF31, IF-31, IF-35, ILIM01, IL-IM-01, IN-1, K2533, K32010CB, K3MFC2010F, R0183114, R200, R-200, R-400, SBS70524, SBS7052-4, USC100, WF283, WIC, WIC6A, WIC-6A, WICS, WPRO, WR97X180, WR97X214, WR97X215, WSF100, WSF-100, WSI-1, WSS3, WSS-3, FFU00P, FFU00P, 33515, FFU00P, 41707, NUP1811, SXBD922FWD
Keep in mind:
- The UF Membrane requires quite a long flush, typically 20 - 30 minutes to remove all the preservatives that give a bitter taste.
- If the water in your area is of poor quality, you may want to consider the Home Reverse Osmosis System or the Home Ultraviolet Filtration System.
- The 5 Micron Sediment Filter, Generic External Fridge Filter, and 0.2 Ultra-Filtration sets need to be replaced every 12 months. Keep in mind that the 24-month life span is based on a good municipality quality water, depending on the quality of your water source, the life span of the filters may be a great deal less.
- Minerals are too small to be removed by the filters in this filtration unit. Should this be a concern, consider installing the Home Reverse Osmosis System.
Comparison of Inline Fridge Filter Options:
Samsung Original External Filters
10105J – Good Quality – No Bacteria Municipal – No Dirt Source – Low Dust After Filter: Link
Inline Sediment + 10105J – Good Quality – No Bacteria Municipal – Some Dirt Source – Low Dust After Filter: Link
Inline Sediment + 10105J + Ultra Filtration – Good Quality – Some Bacteria Municipal – Some Dirt Source – Very Low Dust After Filter: Link
LG Original External Filters (ADQ73693903 replaced 5231JA2010B, 5231JA2012B)
ADQ73693903 – Good Quality – No Bacteria Municipal – No Dirt Source – Low Dust After Filter: Link
Inline Sediment + ADQ73693903 – Good Quality – No Bacteria Municipal – Some Dirt Source – Low Dust After Filter: Link
Inline Sediment + ADQ73693903 + Ultra Filtration – Good Quality – Some Bacteria Municipal – Some Dirt Source – Very Low Dust After Filter: Link
High Quality Alternative Options
Generic External Fridge Filter – Good Quality – No Bacteria Municipal – No Dirt Source – Low Dust After Filter: Link
Silver Nano External Fridge Filter – Good Quality – Very Low Bacteria Municipal – No Dirt Source – Low Dust After Filter: Link
YourPure - KDF/UF Fridge Filter – Very Good Quality – Some Bacteria Municipal – No Dirt Source – Very Low Dust After Filter: Link
Compact Triple Fridge Filter – Good Quality – Some Bacteria Municipal – Some Dirt Source – Very Low Dust After Filter: Link
Additional Options
Pressure Protection Valve
The plastic pressure protection valve will help to protect the filters from becoming damaged and/or leaking as a result of pressure spikes (also known as water hammering) from the incoming water supply.
