LED In-Tank Germicidal UV Light (Vertical Type)

In-Tank Germicidal UV Light helps to control and prevent the growth of bacteria inside your storage tank.

The Vertical Type Germicidal UV Light is designed to be "fixed" to the lid or top of the tank, and then hang in the center of the tank.

The in-tank UV light has a lifetime of 10000 operating hours, then needs to be replaced.

Benefits

• NEW power-efficient 14W 12v LED UVC Lamp Technology
• Equivalent to a 55w traditional UV bulb
• Eradicates pathogens, bacteria, molds, and yeasts
• Prevents infestations from insects and pests such as mosquitoes
• Prevents foul-smelling water by destroying bacterial growth
• Sterilises both air and water inside the tank
• No chemicals, no residue
• Ballast & Lamp housed inside the quartz sleeve
• Easy connection into the tank - only requires 1 hole
• Low maintenance - lamps only require periodic cleaning, once the hour lifetime is reached only the lamp needs to be replaced.
• No Static charge build up in the tank due to the 12V system
• The bulb has just over a year's lifespan, but unlike traditional bulbs, it won't mind not running constantly.

Keep in Mind

• The In-tank UV light does require electricity to operate. The In-Tank UV Light does not come with a storage tank.
• The Quartz Sleeve and UV bulb are made of glass and can be damaged if mishandled. Take great care when transporting and installing the in-tank Germicidal UV Light
• The Effectiveness of the Germicidal UV light is directly influenced by the clarity of the water around it. If there is a great deal of dirt, sediment, and suspended particles then the UV light's effectiveness will be directly affected. If your water does have a high amount of dirt and particles present, then we would recommend placing some type of sediment filter before the tank, such as a Disc Filter, Triple Big Blue System, or AFM Glass Media Vessel.
• While the LED UVC Lamp will address organisms in the water such as bacteria, depending on the source water quality, the water inside of the storage tank may not be fit for human consumption due to other elements such as heavy metals, total dissolved solids, etc. If you are using a non-municipal source water (such as a borehole), then it is highly recommended that you have the water tested first, to ensure that they are no other elements present in the water, that would make it unsafe to drink. It will also not necessarily kill everything as it needs direct light of sight.
• Note that this light is mounted to the tank; it can't hang from its wire or be placed completely in the tank.
• It also shouldn't be mounted in the incoming water stream or horizontally as this might damage the quartz sleeve.

Specifications for the 15w LED In-tank UV Light

• Water Temperature: 4°C - 40°C
• Length - 823mm
• Tank Diameter: <2m
• Tank Height: 1m (Min) to 2m (Max)
• Tank Volume: 5000L (Maximum)
• Lamp Wattage: 14.5W 12-24v with Mains Transformer

• Lamp Life Span: 10 000 hours
• Lamp Wave Length: 270-280 nanometres UVC
• 40 LEDs

Warning!!

• This Appliance contains a UV-C Emitter. Germicidal Lamps Emit UV-C Radiation Harmful to Skin and Eyes.
• Ensure Power is OFF during Installation and before inspecting the tank inside.
